Power Supply

DC 9V（6F22 1PC）

Reference Conditions

23℃±5℃，Below75%rh

Voltage Ranges

380V；6KV；10KV；27.5KV；35KV；110KV；220KV；500KV

Measurement method

Non-contact test

Ranges shift

Manual shift

Wire location

The measured wire is facing the side with lighting lamp

Instrument size

115mm (L)×115mm (W)×169mm (H)

protection class

IP65

Indicating function

Sound and light  Indicating  when the detection voltage exceeds the setting voltage

Power consumption

Max：65mA

Weight

365g（ Including battery ）

Operating temperature and humidity

－10℃～+50℃＜85%RH

Storage temperature and humidity

－15℃～+55℃＜90%RH

Low battery indicating

Have. When the power is low, the instrument emits a low-power light prompt

Battery voltage

When the battery voltage drops to about 5.5V, the low battery voltage signal prompts to replace the battery

Safety regulations

EN 61326-1 CISPR 11

EN 61000-4-2 EN 61000-4-3

EN 61000-4-8
